1060 3003 3004 3005 5052 PVDF , PE Prepainted Color Coated Aluminum Coils / Sheet
| Place of Origin | Zhengzhou Henan China |
|---|---|
| Brand Name | Henan Yongsheng |
| Certification | SGS,ISO,etc. |
| Model Number | Color Coated Aluminum Coil |
| Minimum Order Quantity | 1 ton |
| Delivery Time | 25 days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 5000 tons per month |
| Delivery time | 7-25 Days After Order Confirmation |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Alloy/Grade | 1060 1100 3003 3005 5052 | Temper | O-H112,etc |
|---|---|---|---|
| Thickness | 0.2mm-6.5mm | MOQ | 1 Ton |
| Color | Red, Yellow, White, Black, Wood Grain Color Aluminum Coils, Etc. | Surface Treatment | PVDF Coating , PE Coating, Etc. |
| Application | Building, Roofing, Decoration, Construction , Etc. | ||
| High Light | 5052 Color Coated Aluminum Coils,3005 Color Coated Aluminum Coils,3004 Color Coated Aluminum Coils |
||
Product Description
Product Description:
1060, 3003, 3004, 3005 and 5052 are common alloys used in the production of pre-painted aluminum coils and sheets. These alloys have different properties and are suitable for various applications. PVDF (polyvinylidene fluoride) and PE (polyester) are two commonly used coating materials for color-coated aluminum coils. Here is an overview of the alloys and coating types mentioned above:
1060: Aluminum alloy 1060 is a pure aluminum alloy known for its excellent formability, high corrosion resistance and electrical conductivity. It is often used for general purposes with low strength requirements, such as signs, decorative panels, interior decoration, etc.
3003: Aluminum alloy 3003 is a general-purpose alloy with good formability and medium strength. It has excellent corrosion resistance and is commonly used in construction, roofing, and other general applications that require a combination of strength and corrosion resistance.
3004: Aluminum alloy 3004 has higher strength than 3003. It has good formability, weldability and corrosion resistance. It is commonly used in the production of storage tanks, cans and other applications requiring moderate strength and corrosion resistance.
3005: Aluminum alloy 3005 is similar to 3003 in formability and corrosion resistance, but is stronger. It is commonly used in exterior construction applications such as exterior walls, roofs, and siding.
5052: Aluminum alloy 5052 is a high-strength alloy with excellent corrosion resistance. It is commonly used in marine applications, transportation and structural components where strength, durability and ability to withstand harsh environments are critical.
1060: Aluminum alloy 1060 is a pure aluminum alloy known for its excellent formability, high corrosion resistance and electrical conductivity. It is often used for general purposes with low strength requirements, such as signs, decorative panels, interior decoration, etc.
3003: Aluminum alloy 3003 is a general-purpose alloy with good formability and medium strength. It has excellent corrosion resistance and is commonly used in construction, roofing, and other general applications that require a combination of strength and corrosion resistance.
3004: Aluminum alloy 3004 has higher strength than 3003. It has good formability, weldability and corrosion resistance. It is commonly used in the production of storage tanks, cans and other applications requiring moderate strength and corrosion resistance.
3005: Aluminum alloy 3005 is similar to 3003 in formability and corrosion resistance, but is stronger. It is commonly used in exterior construction applications such as exterior walls, roofs, and siding.
5052: Aluminum alloy 5052 is a high-strength alloy with excellent corrosion resistance. It is commonly used in marine applications, transportation and structural components where strength, durability and ability to withstand harsh environments are critical.
What are PVDF and PE?
PVDF (polyvinylidene fluoride) coating:
PVDF coating is a highly durable, weather-resistant color-coated aluminum coil coating material. It has excellent resistance to UV rays, fading, chalking and chemical exposure. PVDF coated aluminum coils are known for their long-lasting color retention, high gloss and excellent performance in outdoor applications. They are commonly used in building cladding, roofing and other exterior applications where color stability and durability are critical.
PE (polyester) coating:
PE coating is a cost-effective color coated aluminum coil coating material. It has good weather resistance, impact resistance and flexibility. PE coated aluminum coils are available in a variety of colors and finishes, providing a variety of design options. They are commonly used for interior decoration, signage, and other applications that do not require high durability in harsh outdoor environments.
Technical Parameters:
| Name | Color-coated Aluminum Coil |
|---|---|
| Alloy | 1060 1100 3003 3004 3005 5052 |
| Temper | O-H112,etc |
| Thickness | 0.2mm-6.5mm |
| Width | 10mm-1600mm |
| Length | Any |
| Color | Customized |
| Coatings | PVDF or PE |
| MOQ | 1 Ton |
| Application | Building, Roofing, Decoration, Construction , Etc. |
Applications:
1. Architecture and construction:
Roofing and Cladding: Color-coated aluminum coils are commonly used for roofing and cladding applications on residential, commercial and industrial buildings. They are aesthetically pleasing, weather-resistant and durable.
Facades and Curtain Walls: Aluminum coils in vibrant colors and finishes are used to create modern and visually appealing facades on buildings.
Gutters and Downspouts: Color-coated aluminum coils are used in the manufacture of gutters and downspouts due to their corrosion resistance and low maintenance requirements.
2. Transportation:
Automotive: Color-coated aluminum coils are used in the automotive industry for applications such as trim components, trim pieces and license plate plates.
Railway: Aluminum coils with protective coating are used in the railway industry for external panels on train and tram tracks.
3. Electronic and electrical:
Appliances: Color-coated aluminum coils are used in the manufacture of home appliances such as refrigerators, ovens, and air conditioners due to their appearance and corrosion resistance.
Electronic Enclosures: Aluminum coils with protective coatings are used to create enclosures for electronic devices due to their lightweight and durable properties.
4. Signage and display:
Signs: Color-coated aluminum coils are used to create vibrant, eye-catching outdoor advertising signs.
Display Stands: Aluminum coils are used in the manufacture of display stands and exhibition booths due to their light weight and ability to be customized in a variety of colors.
5. Packaging:
Food and Beverage Packaging: Aluminum coils with food grade coating are used in packaging applications in the food and beverage industry as they maintain freshness and protect the contents from external factors.
6. Solar panel industry:
Aluminum coils with highly reflective materials are used to make reflective insulation panels for solar products.
Automotive: Color-coated aluminum coils are used in the automotive industry for applications such as trim components, trim pieces and license plate plates.
Railway: Aluminum coils with protective coating are used in the railway industry for external panels on train and tram tracks.
3. Electronic and electrical:
Appliances: Color-coated aluminum coils are used in the manufacture of home appliances such as refrigerators, ovens, and air conditioners due to their appearance and corrosion resistance.
Electronic Enclosures: Aluminum coils with protective coatings are used to create enclosures for electronic devices due to their lightweight and durable properties.
4. Signage and display:
Signs: Color-coated aluminum coils are used to create vibrant, eye-catching outdoor advertising signs.
Display Stands: Aluminum coils are used in the manufacture of display stands and exhibition booths due to their light weight and ability to be customized in a variety of colors.
5. Packaging:
Food and Beverage Packaging: Aluminum coils with food grade coating are used in packaging applications in the food and beverage industry as they maintain freshness and protect the contents from external factors.
6. Solar panel industry:
Aluminum coils with highly reflective materials are used to make reflective insulation panels for solar products.
Packing and Shipping:
Packaging and Shipping of Color Coated Aluminum Coil
Color Coated Aluminum Coil will be carefully packaged to ensure that it arrives at its destination in perfect condition.
First, the coil will be wrapped in plastic to protect it from dust and scratches. Then, it will be placed in a sturdy wooden crate or pallet to provide additional protection during shipping.
The package will also be labeled with the product name, size, and weight for easy identification and handling.
Depending on the quantity ordered, the coil will be shipped via sea, air, or land transportation. We work with trusted shipping companies to ensure timely delivery and safe handling of the product.
Upon arrival at the destination, our team will carefully inspect the package to ensure that it has not been damaged during transit.
We take great care in packaging and shipping our Color Coated Aluminum Coil to ensure that our customers receive the highest quality product.
FAQ:
- Q: What is the brand name of this product?
A: The brand name of this product is Henan Yongsheng. - Q: What is the model number of this product?
A: The model number of this product is Color Coated Aluminum Coil. - Q: Where is this product manufactured?
A: This product is manufactured in Zhengzhou Henan, China. - Q: What certifications does this product have?
A: This product has SGS, ISO, and other certifications. - Q: What is the minimum order quantity for this product?
A: The minimum order quantity for this product is 3 tons.
