5000 Series Aluminum Coil Manufacturer 5052 5754 5083 5005 5182 Aluminum Sheet Coil strip
| Place of Origin | Gongyi, Henan province,China |
|---|---|
| Brand Name | Yongsheng |
| Certification | SGS |
| Model Number | 5000 series aluminum coil manufacturer 5052 5754 5083 5005 5182 aluminum sheet coil |
| Minimum Order Quantity | 1 tons |
| Price | 1999 USD/Ton |
| Packaging Details | wooden package |
| Delivery Time | 7-21 workdays |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, |
| Supply Ability | 5000tonspermonth |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Keyword | Aluminum Coil 5052，Aluminum Sheet Coil，aluminum Coils Strip | Place Of Origin | Huiguo Town, Gongyi City, Henan Province, China |
|---|---|---|---|
| Alloy/Grade | 5005/5052/5083/5086/5182/5754/5454/5A06/5A05/5251 | Temper | O-H112,T3-T8,T351-T851 |
| Thickness | 0.1mm-6.5mm | Width | 3mm-2600mm |
| Certificate | ISO, RoHS | Standards | ASTM-B209,EN573-1,GB/T3880.1-2006 |
| MOQ | 1 Ton | Delivery Time | 7-25 Days After Order Confirmation |
| Highlight | Aluminum Sheet Coil,aluminum coils strip,aluminum coil 5052 |
||
Product Description
5000 Series Aluminum Coil Products
High-quality 5052, 5754, 5083, 5005, and 5182 aluminum sheet coil strip manufactured to meet industrial standards.
Product Features
- Smooth surface free from cracks, corrosion spots, and nitrate traces
- High fatigue resistance with excellent plasticity and corrosion resistance
- Good weldability with elongation capability of 12-20%
- Environmentally friendly and infinitely recyclable
Applications
5052 aluminum coil offers excellent workability and high fatigue strength with superior corrosion resistance even in salt water environments. Suitable for marine applications including boat bodies, buses, trucks, and trailers. Also used for chemical drums and electronic casings for notebook computers and televisions.
5052 Specifications
Dimensions
| Alloy NO. | Temper | Thickness (mm) | Width (mm) |
|---|---|---|---|
| 5052 | O-H112 | 0.2-300 | Under 2600 |
Mechanical Properties
| Alloy NO./Temper | TS (MPa) | YS (MPa) | Elongation (%) |
|---|---|---|---|
| 5052-H32 | 210-260 | 130 | 5-10 |
Chemical Composition (max, W%)
| Si | Fe | Cu | Mn | Mg | Zn | Cr | Other |
|---|---|---|---|---|---|---|---|
| 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.1 | 0.15-0.35 | - |
Standard Mechanical Properties
| Property | O | H32 | H112 |
|---|---|---|---|
| Tensile Strength (MPa) | ≥ 170 | ≥ 210 | ≥ 190 |
| Yield Strength (MPa) | ≥65 | ≥ 130 | ≥ 70 |
| Elongation (%) | ≥ 12 | ≥ 5 | ≥ 7 |
Product Images
Frequently Asked Questions
Are you a factory or a distributor?
Henan Yongsheng Aluminum Co., Ltd. is a large-scale aluminum sheet/strip/foil manufacturer under Henan Xintai Aluminum Co., Ltd. Founded in 1999, the company covers an area of 380,000 square meters and has 2,100 employees. The company has won the Top 100 Enterprises in Henan Province, the Gold Award of the Economic Benefit Cup, and the Top 30 Enterprises in Zhengzhou City.
How to get a quote?
Please provide the required product thickness, width, length (mm), total demand (tons), so we can provide you with an accurate quotation. Example: 6061 aluminum plate, 3*1220*2440mm, demand 30 tons/month, for mobile phone case.
What is the quotation process?
It depends on the products you ordered. Generally, it takes 7-35 days. We have complete production lines to ensure product quality and production speed.
Can you provide samples?
Yes, we can provide samples for free, but you need to pay for freight initially. We will return the fee after you place an order.
How long can I receive my goods?
Initiate an inquiry → enter demand information → our business manager will quote you within 5 minutes.
Where is your factory located?
Our company is located in Huiguo Town, Gongyi City, Henan Province, which is the largest aluminum industrial cluster in China. We would be pleased to welcome you.
Contact Information
Email: eric@ysaluminum.cn
Phone/WeChat: +86 13027629558
Website: www.aluminumstripcoil.com
