T851 40mm 3004 Weather Aluminum Strip Coil Led Profile For Stairs
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Name | Aluminum Strip Coil | Place Of Origin | China |
---|---|---|---|
Brand | Yongsheng Aluminum Industry Co., Ltd. | Alloy/Grade | 1000series-8000series |
Temper | O - H112 , T3 - T8 , T351 - T851 | Tolerances | As Per Your Requirements |
Thickness | 0.13mm - 5.0mm | Width | 3mm-2600mm |
Length | As Per Your Requirements | Coil ID | As Per Your Requirements |
Highlight | T851 40mm 3004 Weather Aluminum Strip,T851 Aluminum Strip Coil,T851 230Mpa aluminium strip 40mm |
Name : T851 40mm 3004 Weather Aluminum Strip Coil Led Profile For Stairs
Aluminum Strip Description
Aluminum Strip For Louver is a popular base material used in aluminium ROPP / screw / crown caps and other bottle cap closure , which is due to aluminium 3105 alloy properties show excellent deep drawing , formability , corrosion resistance and impressive surface treatment effect ! Similarly , 3105 aluminum strip belongs 3 series Al-Mn anti - rust alloy , which can improve its strength through cold processing . Besides , due to the addition of Mn , the strength between the welds of the Aluminum Strip For Louver is improved , greatly reduces the tendency of cracks , showing good weldability . Therefore, 3105 aluminum strip is also widely used in lamp holder , shutter , sheet metal processing workpiece , color coated aluminum strip , roof panel , corrugated board , etc . Among them , the commonly used ones are 3105 H24 , 3105 H18 aluminum strip .
HENAN YONGSHENG Aluminum Co. , Ltd , A professional manufacturer devoted to Aluminum foil sheet 1050 / 1060 / 1070 3XXX 5XXX 8XXX producion ,The partner you can trust !
We are specialized in aluminum strip manufacturing . The aluminum strip can be used in the production of cars , transformers , air compressor , engineering machinery , air separation equipment and other industries , such as radiators , condensers and evaporators manufacturing .Our Aluminium Strip base cap materials combines strength and high formability with high resistance to softening in vitriting . Manufactured at modern and well - equipped mills , it can be rolled to very fine tolerances , allowing more caps per tonne of coil and enabling uninterrupted operations of high - speed forming presses .
If you want to know more about our Aluminum products or Aluminum Coil , please feel free to contact us , we will reply you within 24 hours .
- Features of the 1 series :
It belongs to a series containing the most aluminum.Contains more than 99.00% aluminum, good electrical conductivity, good corrosion resistance, good welding performance, low strength.Used in conventional industry.
- Features of the 2 series :
The hardness is high, in which the copper element content is the highest, about 3-5%. Mn, magnesium, lead and bismuth are also added for machinability.Used in the field of aviation.
- Features of the 3 series :
It is mainly composed of manganese.The content is between 1.0% and 1.5%, used for industries and products with high requirements for rust prevention.Good corrosion resistance, good weldability and good plasticity.
- Features of the 5 series :
It belongs to the series of commonly used alloy aluminum plate, the main element is magnesium.The main characteristics are low density, high tensile strength, high elongation, good fatigue strength, but can not be strengthened by heat treatment.It is also widely used in conventional industry.
- Features of the 6 series :
Contains mainly magnesium and silicon, suitable for corrosion resistance, oxidation demanding applications.
- Features of the 7 series :
It belongs to aeronautical series, aluminum magnesium zinc copper alloy, heat treatable alloy, super hard aluminum alloy, has good wear resistance, also has good weldability, but corrosion resistance is poor.
Alloy | State | Thickness(mm) | Tensile Strength(Mpa) | The Yield Strength(Mpa) | elongation(%) | hardness(HV) |
1060 (1050) |
0 | >0.2-0.5 | 60-100 | ≥15 | ≥20 | 20-30 |
>0.5-1.0 | ≥30 | |||||
>1.0-4.0 | ≥35 | |||||
H22 | >0.2-0.5 | 80-120 | ≥60 | ≥12 | 30-40 | |
>0.5-1.0 | ≥15 | |||||
>1.0-4.0 | ≥18 | |||||
H24 | >0.2-0.5 | 95-135 | ≥70 | ≥6 | 35-45 | |
>0.5-1.0 | ≥8 | |||||
>1.0-4.0 | ≥10 | |||||
H26 | >0.2-0.5 | 110-155 | ≥75 | ≥2 | 43-55 | |
>0.5-1.0 | ≥4 | |||||
>1.0-4.0 | ≥6 | |||||
H18 | >0.2-0.5 | ≥125 | ≥85 | ≥2 | 50-65 | |
>0.5-1.0 | ≥3 | |||||
>1.0-4.0 | ≥4 | |||||
1100 (1200) |
0 | >0.2-0.5 | 75-105 | ≥25 | ≥18 | 25-30 |
>0.5-1.0 | ≥30 | |||||
>1.0-4.0 | ≥35 | |||||
H22 | >0.2-0.5 | 95-130 | ≥75 | ≥12 | 30-40 | |
>0.5-1.0 | ≥15 | |||||
>1.0-4.0 | ≥18 | |||||
H24 | >0.2-0.5 | 110-145 | ≥95 | ≥6 | 38-40 | |
>0.5-1.0 | ≥8 | |||||
>1.0-4.0 | ≥10 | |||||
H26 | >0.2-0.5 | 130-165 | ≥115 | ≥2 | 45-60 | |
>0.5-1.0 | ≥4 | |||||
>1.0-4.0 | ≥6 | |||||
H18 | >0.2-0.5 | ≥150 | ≥130 | ≥2 | 55-70 | |
>0.5-1.0 | ≥3 | |||||
>1.0-4.0 | ≥4 | |||||
3003 (3A21) |
0 | > 0.2-0.5 | 95-140 | ≥ 35 | ≥ 15 | 30-40 |
> 0.5-1.0 | ≥ 30 | |||||
> 1.0-4.0 | ≥ 35 | |||||
H22 | > 0.2-0.5 | 120-160 | ≥90 | ≥ 12 | 39-53 | |
> 0.5-1.0 | ≥ 15 | |||||
> 1.0-4.0 | ≥ 18 | |||||
H24 | > 0.2-0.5 | 145-195 | ≥125 | ≥ 6 | 42-59 | |
> 0.5-1.0 | ≥ 8 | |||||
> 1.0-4.0 | ≥ 10 | |||||
H26 | > 0.2-0.5 | 170-210 | ≥150 | ≥ 2 | 55-65 | |
> 0.5-1.0 | ≥ 4 | |||||
> 1.0-4.0 | ≥ 6 | |||||
H18 | > 0.2-0.5 | ≥ 190 | ≥ 170 | ≥ 2 | 60-85 | |
> 0.5-1.0 | ≥ 3 | |||||
> 1.0-4.0 | ≥ 4 | |||||
3004 (3104) |
0 | > 0.2-0.5 | 155-200 | ≥ 60 | ≥ 13 | 49-62 |
> 0.5-1.0 | ≥ 16 | |||||
> 1.0-4.0 | ≥ 20 | |||||
H22 | > 0.2-0.5 | 190-240 | ≥ 145 | ≥ 10 | 60-84 | |
> 0.5-1.0 | ≥ 12 | |||||
> 1.0-4.0 | ≥ 14 | |||||
H24 | > 0.2-0.5 | 220-265 | ≥ 170 | ≥ 8 | 68-100 | |
> 0.5-1.0 | ≥ 10 | |||||
> 1.0-4.0 | ≥ 12 | |||||
H26 | > 0.2-0.5 | 240-285 | ≥ 190 | ≥ 3 | 72-110 | |
> 0.5-1.0 | ≥ 4 | |||||
> 1.0-4.0 | ≥ 6 | |||||
H18 | > 0.2-0.5 | ≥ 260 | ≥ 230 | ≥ 2 | 85-120 | |
> 0.5-1.0 | ≥ 2 | |||||
> 1.0-4.0 | ≥ 3 | |||||
3005 | 0 | >0.2-0.5 | 115-165 | ≥45 | ≥13 | 35-45 |
>0.5-1.0 | ≥20 | |||||
>1.0-4.0 | ≥25 | |||||
H22 | >0.2-0.5 | 145-195 | ≥110 | ≥10 | 40-60 | |
>0.5-1.0 | ≥15 | |||||
>1.0-4.0 | ≥15 | |||||
H24 | >0.2-0.5 | 170-215 | ≥130 | ≥6 | 58-70 | |
>0.5-1.0 | ≥8 | |||||
>1.0-4.0 | ≥10 | |||||
H26 | >0.2-0.5 | 195-240 | ≥160 | ≥3 | 65-83 | |
>0.5-1.0 | ≥4 | |||||
>1.0-4.0 | ≥6 | |||||
H18 | >0.2-0.5 | ≥220 | ≥200 | ≥2 | 80-100 | |
>0.5-1.0 | ≥3 | |||||
>1.0-4.0 | ≥3 | |||||
3105 | 0 | >0.2-0.5 | 75-105 | ≥25 | ≥14 | 32-42 |
>0.5-1.0 | ≥20 | |||||
>1.0-4.0 | ≥25 | |||||
H22 | >0.2-0.5 | 95-130 | ≥75 | ≥10 | 39-60 | |
>0.5-1.0 | ≥12 | |||||
>1.0-4.0 | ≥12 | |||||
H24 | >0.2-0.5 | 110-145 | ≥95 | ≥8 | 52-62 | |
>0.5-1.0 | ≥10 | |||||
>1.0-4.0 | ≥10 | |||||
H26 | >0.2-0.5 | 130-165 | ≥115 | ≥3 | 58-72 | |
>0.5-1.0 | ≥4 | |||||
>1.0-4.0 | ≥6 | |||||
H18 | >0.2-0.5 | ≥150 | ≥130 | ≥2 | 65-95 | |
>0.5-1.0 | ≥2 | |||||
>1.0-4.0 | ≥3 | |||||
5005 | 0 | >0.2-0.5 | 100-145 | ≥35 | ≥15 | 33-43 |
>0.5-1.0 | ≥20 | |||||
>1.0-4.0 | ≥25 | |||||
H22 | >0.2-0.5 | 125-165 | ≥80 | ≥12 | 30-53 | |
>0.5-1.0 | ≥15 | |||||
>1.0-4.0 | ≥18 | |||||
H24 | >0.2-0.5 | 145-185 | ≥110 | ≥8 | 40-60 | |
>0.5-1.0 | ≥10 | |||||
>1.0-4.0 | ≥10 | |||||
H26 | >0.2-0.5 | 165-205 | ≥135 | ≥3 | 50-68 | |
>0.5-1.0 | ≥4 | |||||
>1.0-4.0 | ≥6 | |||||
H18 | >0.2-0.5 | ≥185 | ≥165 | ≥2 | 57-68 | |
>0.5-1.0 | ≥2 | |||||
>1.0-4.0 | ≥3 | |||||
5052 (5251) |
0 | > 0.2-0.5 | 170 - 215 | ≥ 65 | ≥ 14 | 50 - 70 |
> 0.5-1.0 | ≥ 17 | |||||
> 1.0-4.0 | ≥ 20 | |||||
H22 | > 0.2-0.5 | 210 - 260 | ≥ 130 | ≥ 8 | 70 - 85 | |
> 0.5-1.0 | ≥ 10 | |||||
> 1.0-4.0 | ≥ 10 | |||||
H24 | > 0.2-0.5 | 230 - 280 | ≥ 150 | ≥ 4 | 80 - 110 | |
> 0.5-1.0 | ≥ 6 | |||||
> 1.0-4.0 | ≥ 6 | |||||
H26 | > 0.2-0.5 | 250 - 300 | ≥ 180 | ≥ 2 | 85 - 115 | |
> 0.5-1.0 | ≥ 4 | |||||
> 1.0-4.0 | ≥ 6 | |||||
H18 | > 0.2-0.5 | ≥ 270 | ≥ 240 | ≥ 2 | ||
> 0.5-1.0 | ≥ 2 | |||||
> 1.0-4.0 | ≥ 3 |
Aluminum Strip Technical Data
- Alloy / Grade : 1000 Series , 2000 Series , 3000 Series , 5000 Series , 6000 Series , 7000 Series , 8000 Series
- Temper : O - H112 , T3 - T8 , T351 - T851
- Thickness : 0.13mm - 6.5mm
- Width : 3mm - 2600mm
- Length : As per your requirements
- Size : Customized Size
- Feature : Eco-friendly
-
Package : Wooden Pallets
-
Type : High Purity Aluminium Strip
- Color : Silver
- Shape : Alu Strip
- Hardness:O/HO
- Conductivity ( % IACS ) : ≥61.5
- Elongation ( % ) : > 23
- Tolerances : As per your requirements
- Application : Industry , Decoration , Building , Packing , Pressing , Etc .
- Surface treatment : Mill Finish , Coated , Powder Coated , Anodized , Polished mirror , Embossed , Etc .
- Special Specification is available on customer ’ s requirement
- Delivery time : 7-30 days after order confirmation
- MOQ : 1 ton
- Coil ID : As per your requirements
Aluminum Strip Use
- Aluminum Strip for transformer ( aluminum foil for transformer )
- Aluminum Strip for high-frequency welding hollow aluminum strip
- Aluminum Strip for finned radiator
- Aluminum Strip for cable
- Aluminum Strip for stamping
- Aluminum Strip for edge strip , etc .
Aluminum Alloy Belt Categories :
- pure aluminum strip
- transformer aluminum strip
- super hard aluminum strip
- all soft aluminum strip
- semi hard aluminum strip
- rust proof aluminum strip
FAQ
1. who are we?
Henan Yongsheng Aluminum Co. , Ltd . is located in Gongyi City Industrial Cluster Area , Henan Province . The factory focuses on the production and development of aluminum products such as Aluminum Strip , Color Aluminum , Aluminum Sheet , Aluminum Coil , Pressed Aluminum Product , Embossed Aluminum , and non-slip aluminum Sheet . The factory covers an area of 100 , 000 square meters , has 476 employees , has 20 casting processing production lines , 2 color coated aluminum coil production lines , 3 slitting production lines , 4 shearing production lines , 32 punch presses , 10 CNC lathes , 4 The embossed aluminum production line has an annual output of more than 200 , 000 tons , and exports account for more than 40 % .
2. how can we guarantee quality?
1 - we can provide samples . We can send the samples by TNT,DHL, FEDEX, EMS, UPS or to your warehouse .
2 - Always a pre-production sample before mass production .
3 - Always final Inspection before shipment .
3. How long will it take to execute my order?
Our normal produce time is 7-15 working days.
4. How much will the shipping cost be?
This will depend on the size and weight of your order and the method of shipping.
5. Do you have products in stock?
There are 10000 tons stock for various size .plsease inform us what model you need , we will send stock details to you .
6. why should you buy from us not from other suppliers?
1 - 20 years experience in aluminum industry .
2 - Source manufacturers, leading equipment, excellent team skills .
3 - Low price, fast delivery and excellent quality .
4 - Professional technical solution .
7. what services can we provide?
1 - Accepted Delivery Terms : FOB , CFR , CIF , EXW , CIP , CPT , DDP , DDU ;
2 - Accepted Payment Currency : USD , EUR , HKD , GBP , CNY;
3 - Accepted Payment Type : T / T , L / C,D/P D/A , , Credit Card , PayPal , Western Union , Cash , Escrow ;
4 - Language Spoken : English , Chinese , Spanish , Japanese , Portuguese , Korean .
Packing conditions
Packing details :
- l Normally , for aluminium strip , 20MT can be loaded into 20 foot container , we suggest to use 20 foot container , the sea freight rate is much cheaper than 40 foot container .
- l the packing is very strong , which has 3 lays , thick fiber , foam , plastic , enough drying agent , suitable for long distance sea transportation .
- l We use wooden pallet and steel pallet according to customer request ;
- l Wooden boxes will be used in the outside packing .
- l We have fixing in the container to avoid any damage during the transportation .
- l 24 wooden boxes in one 20ft container .
Reliable quality , reasonable price and prompt delivery are insured to be offer to you .
TELL US WHAT U NEED , THEN WE WILL TRY OUR BEST .
